RM Series with Dual Setting Controller
Intelligent Reactive Power Management – RM Series Dual Setting Controller
Description
- Intelligent RM Series P.F. Controllers are used for measurement and control of P.F. control units for central reactive power compensation. The P.F. measured by Neptune RM Plus is compared with the set values and in order to provide necessary compensation. P.F. Controller switches capacitor banks ON & OFF automatically. RM Plus is Single Phase CT Sensing micro controller relay, designed for above application in 144×144 case for flush mounting with rear plug-in connectors. Microcontroller based programmable RM Plus series relays are manufactured with 8 & 12 capacitor steps. It can work either in automatic or manual mode.
Features
- Intelligent Switching for Balanced Load Compensation
- Dual Target Cos Phi (For Mains & Generator PF Compensation)
- Password Protection
- Internal Temp. Control
- Automatic Setup
- Measures and displaying upto 19th harmonics for voltage & current
- Programmable discharge time
- Automatic calculation of power values for each capacitor step
Auto / Manual mode selection
- 10 different programs
- C+ / NORMAL / C- condition light
- Automatic calculation on C/k value
- Automatic calculation on C/k value
- Optional temperature control with J type T/C input
- Insufficient compensation alarm
- Over compensation alarm
Programmable over voltage protection and alarm for capacitors
- Automatic disconnection of all capacitor steps in case of Mains failure over 20 sec.
- Programmable CT and PT ratio setting
- Non-flammable enclosure
Mechanical Parameters
| # | Parameters |
|---|---|
| Equipment Protection | Double Insulation, Measurement Category III |
| Ambient Op. Temperature | -5 C, +55 C |
| Ambient Humidity | 95% |
| Degree of Protection | IP40 (Front Panel) |
| Connection / Installation | Terminal / Flush-mounting with rear terminals |
| Dimensions | 144×144 mm |
| Capacitor Loss | < 0.5 watt/ KVAr |
Electrical Parameters
| # | Parameters |
|---|---|
| Operating Voltage (Un) | 230V AC ±10%, 50/60Hz |
| Operating Current | 100 mA – 5.5A |
| Capacitors Steps | 8 / 12 |
| Network Type | Single Phase, 1 CT |
| Accuracy | 1% ±1 digit (V, I, cos phi) 2% ±1 digit (W, Var, VA) |
| Current Transformer Ratio | 5…10000/5A |
| Power Consumption | < 2 VA (Current Circuit) < 3 VA – 10 VA (Voltage Circuit) |
| Cos Phi Setting | 0.8 < Cos phi |
| C/k Setting | 0,02 – 1,00 |
| Time Delay Between Steps | 1-1.800 Sec. (for switch on / off separately) Discharge Time (Reconnection Time) – 1-1.800 Sec. |
| Over Voltage Setting | 240-275V AC |
| Output Contact | 3A, 750VA |
| Display | Red LED, 14 mm Height (144x144mm) |
| Dual Target Cos Phi (For Mains & Generator) | Yes |
| Automatic Energy Correction | Yes |
| Automatic Disconnection of Damaged Cap. Steps | Yes |
| Programmable THD-I and THD-V Alarm | NO |
| Programmable Discharge Time | Yes |
| Programmable Over Voltage Alarm | Yes |
| Automatic Over Voltage Alarm | Yes |
| Automatic Power Calculation | Yes |
| Programmable Energy Ratio Alarm | Yes |
| Password Protection for Setup | Yes |
| RS-485 Communication | NO |
| Alarm Contact Output (Over Voltage, Harmonics) | Yes |
| Upto 19th Harmonics | NO |
| THD-I%, THD-V% | NO |
| Phase-Neutral Voltage (VLN) | Yes |
| Phase-Phase Voltage (VLL) | Yes |
| Phase Current (I)
(VLL) |
Yes |
| Active Power (P) | Yes |
| Reactive Power (Q) | Yes |
| Apparent Power (S) | Yes |
